LPA2101A
Filterless 30W Class F Mono Audio Amplifier With AGC function
概述
The LPA4809 is a dual audio power amplifier capable of delivering 140mW per channel of continuous average power into a 16Ω load with 0.1 %(THD+N) from a 5V power supply. Boomer audio power amplifier was designed specifically to provide high quality output power with a minimal amount of external components. Since the LPA4809 does not require bootstrap capacitors or snubber networks, it is optimally suited for low-power portable systems. The unity-gain stable LPA4809 can be configured by external gain-setting resistors.The LPA4809 features an externally controlled, active-low, micro power consumption shutdown mode, as well as an internal thermal shutdown protection mechanism.
应用
◆Microphone Preamplifier
◆Personal Computers
◆PDA`s
◆Personal Computers
◆PDA`s
数据参数
数据参数
输入电压(V)
2~5.5
工作类型
Class AB
通道数量
2
电源抑制比(dB)
-70
输出功率
140mW*2,5V@16Ω,0.1%
关断电流(uA)
2
特点
0.4uA Single ended input,High efficiency,Enough output power,Low noise
封装
MSOP8
特征
特征
◆THD+N at 1KHz at 140mW continuous average power into 16Ω 0.1%
◆THD+N at 1KHz at 80mW continuous average power into 32Ω 0.1%
◆Shutdown Current 0.5uA
◆Active-low shutdown mode
◆ “Click and Pop” reduction circuitry
◆Low shutdown current
◆MSOP8 surface mount packaging
◆No bootstrap capacitors required
◆Unity-gain stable
◆THD+N at 1KHz at 80mW continuous average power into 32Ω 0.1%
◆Shutdown Current 0.5uA
◆Active-low shutdown mode
◆ “Click and Pop” reduction circuitry
◆Low shutdown current
◆MSOP8 surface mount packaging
◆No bootstrap capacitors required
◆Unity-gain stable
