LP3219
1.5MHz, 2A Step-Down Converter
概述
The LP6498H is a synchronous step-down regulator from a high voltage input supply. Operating with an input voltage range from 8V to 30V and 1.2A continuous output current. The converter integrates a main switch and a synchronous rectifier for high efficiency without an external schottky diode.LP6498H requires a minimum number of readily available standard external components, over current protection and thermal shutdown, output short circuit protection.The LP6498H converters are available in the industry standard SOP-8 and DIP-8 packages.
应用
◆ Car Charger / Adaptor
◆ Pre-Regulator for Linear Regulators
◆ Distributed Power Systems
◆ USB Dedicated Charging Ports (DCP)
◆ Pre-Regulator for Linear Regulators
◆ Distributed Power Systems
◆ USB Dedicated Charging Ports (DCP)
数据参数
数据参数
输入电压(V)
8~36
输出电压(V)
5.1
FB电压（V）
-
电压精度
±3%
工作频率(Hz)
200K
最大输出电流(A)
1.2
输出通道数量
1
工作模式
Syn.
EN控制
N
轻负载模式
FCCM
产品特征/功能
Internal Soft Start,OCP,SCP,OTP
封装
SOP8
特征
特征
◆ Input Voltage Range: 8V to 30V
◆ Output Voltage: 5.1V
◆ 1200mA Load Current
◆ Up to 93% Efficiency
◆ 200KHz Switching Frequency
◆ Short Circuit Protection
◆ Thermal Fault Protection
◆ SOP-8 Package
◆ RoHS Compliant and 100% Lead (Pb)-Free
◆ Output Voltage: 5.1V
◆ 1200mA Load Current
◆ Up to 93% Efficiency
◆ 200KHz Switching Frequency
◆ Short Circuit Protection
◆ Thermal Fault Protection
◆ SOP-8 Package
◆ RoHS Compliant and 100% Lead (Pb)-Free
