LP3219
1.5MHz, 2A Step-Down Converter
概述
The LP6493 is a synchronous step down regulator with CC control from a high voltage input supply. Operating with an input voltage 8V~30V, the LP6493 achieves 3.5A continuous output current with excellent load and line regulation. Current mode operation provides fast transient response and eases loop stabilization.The LP6493 requires a minimum number of readily available standard external components. Other features include cable compensation, programmable current limit and thermal shutdown. The LP6493 converters are available in the industry standard SOP8 packages.
应用
◆ Car Charger / Adaptor
◆ Pre-Regulator for Linear Regulators
◆ Distributed Power Systems
◆ Battery Charger
◆ Pre-Regulator for Linear Regulators
◆ Distributed Power Systems
◆ Battery Charger
数据参数
数据参数
输入电压(V)
8.0~36
输出电压(V)
0.6~30
FB电压（V）
0.6
电压精度
±2%
工作频率(Hz)
180K
最大输出电流(A)
3.4
输出通道数量
1
工作模式
Syn.
EN控制
N
轻负载模式
FCCM
产品特征/功能
Adjustable output current limit,Line compensation
封装
SOP8
特征
特征
◆ Wide 8V to 30V Continuous Operating Input Range
◆ 58mΩ/45mΩ Low RDS(ON) Internal Power MOSFET
◆ Up to 93% Efficiency
◆ Default 180kHz Switching Frequency
◆ Internal Soft Start
◆ Output Line Drop Compensation
◆ Over-Current Protection (OCP) programmable with External Resistor
◆ No Loop Compensation Required
◆ Thermal Shutdown
◆ Available in SOP-8 Package
◆ 58mΩ/45mΩ Low RDS(ON) Internal Power MOSFET
◆ Up to 93% Efficiency
◆ Default 180kHz Switching Frequency
◆ Internal Soft Start
◆ Output Line Drop Compensation
◆ Over-Current Protection (OCP) programmable with External Resistor
◆ No Loop Compensation Required
◆ Thermal Shutdown
◆ Available in SOP-8 Package
