LP3219
1.5MHz, 2A Step-Down Converter
概述
The LP6483 contains an independent 340KHz constant frequency, current mode, PWM step-down converters. The converter integrates a main switch and a synchronous rectifier for high efficiency without an external Schottky diode. The converter can supply 3A of load current. The LP6483 can also run at 98% duty cycle for low dropout applications. It provides fast transient response and cycle-by-cycle limit with current mode control. The LP6483 is available in a ESOP8 package and is rated over the -40°C to 85°C temperature range.
应用
◆ Portable Media Players
◆ Cellular and Smart mobile phone
◆ PDA/DSC
◆ GPS Applications
◆ Cellular and Smart mobile phone
◆ PDA/DSC
◆ GPS Applications
数据参数
数据参数
输入电压(V)
4.5~36
输出电压(V)
0.6~12
FB电压（V）
0.6
电压精度
±2%
工作频率(Hz)
340K
最大输出电流(A)
3
输出通道数量
1
工作模式
Syn.
EN控制
Y
轻负载模式
FCCM
产品特征/功能
Internal Soft Start,OCP,SCP,OTP
封装
ESOP8
特征
特征
◆ Input Voltage Range: 4.5V to 30V
◆ Output Voltage Range: 0.6V to 12V
◆ 3A Load Current
◆ Up to 95% Efficiency
◆ 340KHz Switching Frequency
◆ Short Circuit Protection
◆ Thermal Fault Protection
◆ ESOP8 Package
◆ RoHS Compliant and 100% Lead (Pb)-Free
◆ Output Voltage Range: 0.6V to 12V
◆ 3A Load Current
◆ Up to 95% Efficiency
◆ 340KHz Switching Frequency
◆ Short Circuit Protection
◆ Thermal Fault Protection
◆ ESOP8 Package
◆ RoHS Compliant and 100% Lead (Pb)-Free
