LP3219
1.5MHz, 2A Step-Down Converter
概述
The LP6461 is a synchronous buck converter supporting up to 3A output current. The LP6461 operates over a wide input voltage range from 4.5V to 16V and integrates main switch and synchronous switch with very low RDS(ON) to achieve high efficiency. The LP6461 integrates two operation modes, PWM control and PFM mode switching control, which allows a high efficiency over the wider range of the load. Other features include over current protection(OCP), over temperature protection(OTP), under-voltage lockout(UVLO)and short circuit protection(SCP).The LP6461 is available in a space saving SOT23-6 package.
应用
◆ Portable Media Players
◆ Cellular and Smart mobile phone
◆ PDA/DSC
◆ GPS Applications
◆ Cellular and Smart mobile phone
◆ PDA/DSC
◆ GPS Applications
数据参数
数据参数
输入电压(V)
4.5~16
输出电压(V)
0.6~12
FB电压（V）
0.6
电压精度
±2%
工作频率(Hz)
600K
最大输出电流(A)
3
输出通道数量
1
工作模式
Syn.
EN控制
Y
轻负载模式
PFM/PWM
产品特征/功能
Internal Soft Start,OCP,SCP,OTP
封装
SOT23-6
特征
特征
◆ Input Voltage Range: 4.5V to 16V
◆ Output Voltage Range: 0.6V to 12V
◆ 3A Load Current on Channel
◆ Up to 95% Efficiency
◆ 600KHz Switching Frequency
◆ Short Circuit Protection
◆ Over-Temperature Protection
◆ SOT23-6 Package
◆ RoHS Compliant and Halogen Free
◆ Pb-Free Package
◆ Output Voltage Range: 0.6V to 12V
◆ 3A Load Current on Channel
◆ Up to 95% Efficiency
◆ 600KHz Switching Frequency
◆ Short Circuit Protection
◆ Over-Temperature Protection
◆ SOT23-6 Package
◆ RoHS Compliant and Halogen Free
◆ Pb-Free Package
