LP3810
概述
LP3809 is a series of high precision voltage detector with ultra low current consumption. It can work at very low voltage, which makes it perfect for system reset.LP3809 is composed of high precision voltage reference, comparator, delay circuit, output driver and resistor array. Internally preset detect voltage has a low temperature drift and requires no external trimming.LP3809 is available in SOT-23 packages which are Pb free.
应用
◆ Power monitor for portable equipment
◆ PDA, DSC, Mobile phone,Notebook,MP3
◆ CPU and Logic Circuit Reset
◆ Battery Checker
◆ Battery Back-up Circuit
◆ Power Failure Detector
◆ PDA, DSC, Mobile phone,Notebook,MP3
◆ CPU and Logic Circuit Reset
◆ Battery Checker
◆ Battery Back-up Circuit
◆ Power Failure Detector
数据参数
数据参数
输入电压(V)
0.9~6
电压检测(V)
2.63、2.93
复位状态
Active Low
延迟时间(mS)
240
输出类型
Push-Pull
静态电流(uA)
3
产品特征/功能
High Precision,Ultra low current consumption
封装
SOT23
特征
特征
◆ High-precision detection Voltage 3%
◆ Detection Voltage 0.9V~5.5V (in 0.1V steps)
◆ Precise hysteresis 4% typ.
◆ Operating Voltage range 0.9V~5.5V
◆ Detection Voltage 0.9V~5.5V (in 0.1V steps)
◆ Precise hysteresis 4% typ.
◆ Operating Voltage range 0.9V~5.5V
